2011 2014 Aluminum Alloy Bar Solid Rod Mill Edge 180mm 250mm 260mm 270mm

Product Categories
Wuxi Jianbang Haoda Steel Co., Ltd
Contact Now

2011 2014 Aluminum Alloy Bar Solid Rod Mill Edge 180mm 250mm 260mm 270mm

Brand Name : JBHD

Model Number : 2011 2014

Certification : ISO9001

Place of Origin : China

MOQ : 1 ton

Price : Negotiation

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 10000 Ton

Delivery Time : 7-15 working days

Packaging Details : Standard seaworthy package

Edge : Mill Edge Slit Edge

Technique : EXTRUDED

Temper : H14

Surface : Mill Finish Polished

Material : Aluminun Alloy

Price term : EXW FOB CIF CFR

Contact Now

180mm 250mm 260mm 270mm 2011 2014 Aluminum Bar

What is 2024 grade aluminium?

2024 aluminium alloy is an aluminium alloy, with copper as the primary alloying element. It is used in applications requiring high strength to weight ratio, as well as good fatigue resistance. It is weldable only through friction welding, and has average machinability.

What is 2024 Aluminium alloy used for?

2024 aluminum is an alloy that is often used in the aerospace industry. It is a high-strength alloy suitable for projects requiring a high strength-to-weight ratio and excellent fatigue resistance. As such, it is primarily found in wing and fuselage structures that frequently come under tension.
What is grade 2024 t3 aluminium?
This is one of the best known of the high strength aluminium alloys. With its high strength and excellent fatigue resistance, it is used to advantage on structures and parts where good strength-to-weight ratio is desired. It is readily machined to a high finish.
What is the difference between 2024 T4 and T6?
2024 is an age-hardening aluminum alloy and responds to heat treatment to accomplish the strengthening (aging). The T4 condition is attained by a 920°F heating followed by a cold water quench and aging at room temperature. T6 is attained by the same 920°F and quenched followed by a 375°F for 10 hours and air cooling.
Products Name aluminum bars
Material Aluminum
Other Material 1060, 1050, 1070, 1100, 3003, 3004, 5052,
5652, 5154, 5254, 5454, 5083, 5086, 5056,
5456, 2024, 2014, 6061, 6063 ,etc
Standard ASTM, SUS, DIN etc
Surface Bright, polished, hair line, brush, embossed, etc
Payment Term L/C , D/A , D/P , T/T , West Union , Money Gram , other
Price Term FOB, CIF, CFR , CNF etc
Package Export standard package:bundled wooden box or be required;
The inner size of container is below:
(1)20 foot GP:5.8m(length)x2.13m(width)x2.18m(high)about24-26 CBM
(2)40 foot GP:11.8m(length)x2.13m(width)x2.72m(high)about68 CBM
Delievery Time 5-15days
Loading Port china
Supply Ability 3000 tons per yaer

2011 2014 Aluminum Alloy Bar Solid Rod Mill Edge 180mm 250mm 260mm 270mm

Alloy Si Fe Cu Mn Mg Cr Zn Ti OTHERS OTHERS Al
1050 0.25 0.4 0.05 0.05 0.05 — 0.05 0.03 0.03 — 99.5
1070 0.2 0.25 0.04 0.03 0.03 — 0.04 0.03 0.03 — 99.7
1100 0.95 Si + Fe 0.05-0.20 0.05 — — 0.1 — 0.05 0.15 99
2024 0.5 0.5 3.8-4.9 0.30-0.9 1.2-1.8 0.1 0.25 0.15 0.05 0.15 Rem.
3003 0.6 0.7 0.05-0.20 1.0-1.5 — — 0.1 — 0.05 0.15 Rem.
3004 0.3 0.7 0.25 1.0-1.5 0.8-1.3 — 0.25 — 0.05 0.15 Rem.
3005 0.6 0.7 0.3 1.0-1.5 0.20-0.6 0.1 0.25 0.1 0.05 0.15 Rem.
5005 0.3 0.7 0.2 0.2 0.50-1.1 0.1 0.25 — 0.05 0.15 Rem.
5052 0.25 0.4 0.1 0.1 2.2-2.8 0.15-0.35 0.1 — 0.05 0.15 Rem.
5252 0.08 0.1 0.1 0.1 2.2-2.8 — 0.05 — 0.03 0.1 Rem.
6061 0.40-0.8 0.7 0.15-0.40 0.15 0.8-1.2 0.04-0.35 0.25 0.15 0.05 0.15 Rem.
7075 0.4 0.5 1.2-2.0 0.3 2.1-2.9 0.18-0.28 5.1-6.1 0.2 0.05 0.15 Rem.

2011 2014 Aluminum Alloy Bar Solid Rod Mill Edge 180mm 250mm 260mm 270mm

Alloy Temper Tensile Strength Yield Strength Elongation (%) Tensile Strength Yield Strength
(ksi) (ksi) 0.01-0.05 in 0.051-0.125 in (MPa) (MPa)
1100 H12 16 15 4 12 110.3 103.4
H14 18 17 3 10 124.1 117.2
3003 H12 19 18 9 11 131 124.1
H14 22 21 3 7 151.7 144.8
3004 H32 31 25 6 15 213.7 172.4
H34 35 29 5 10 241.3 199.9
3005 H12 26 24 5 13 179.3 165.5
H14 29 28 4 9 199.9 193.1
5005 H12 20 19 5 9 137.9 131
H14 23 22 4 7 158.6 151.7
5052 H32 33 28 7 10 227.5 193.1
H34 38 31 6 8 262 213.7
5056 O 42 22 23 24 289.6 151.7
H38 60 50 6 13 413.7 344.7
6061 T4 35 21 22 24 241.3 144.8
T6 45 40 12 17 310.3 275.8
7075 O 33 15 16 18 227.5 103.4
T6 83 73 11 12 572.3 503.

Product Show

2011 2014 Aluminum Alloy Bar Solid Rod Mill Edge 180mm 250mm 260mm 270mm

2011 2014 Aluminum Alloy Bar Solid Rod Mill Edge 180mm 250mm 260mm 270mm
2011 2014 Aluminum Alloy Bar Solid Rod Mill Edge 180mm 250mm 260mm 270mm
2011 2014 Aluminum Alloy Bar Solid Rod Mill Edge 180mm 250mm 260mm 270mm2011 2014 Aluminum Alloy Bar Solid Rod Mill Edge 180mm 250mm 260mm 270mm
Company Introduction
2011 2014 Aluminum Alloy Bar Solid Rod Mill Edge 180mm 250mm 260mm 270mm
Certification
2011 2014 Aluminum Alloy Bar Solid Rod Mill Edge 180mm 250mm 260mm 270mm
2011 2014 Aluminum Alloy Bar Solid Rod Mill Edge 180mm 250mm 260mm 270mm
